Semi Automatic Blow Molding Machine 2L-4L
Send Inquiry

Servo motor injection machine was most good at injection thermoplastic plastic material, such as PP (Polypropylene), PE (Polyethylene)
Our machine has bigger tie bar space and shot weight capacity, it is enough capacity to produce your demand all kind of plastic product

GENERAL INFO

SG2L

SG2L/2

Configuration

One main blowing machine

      One infrared heater

One main blowing machine

    Two infrared heater

Theoretical output

     700PCS/hr 1500PCS/hr

    2000PCS/hr 1000PCS/hr

Heating capacity

               9.8kw

               15kw

Max bottle volume

     4L(1 cavity) 2L(2 cavity)

  2.0L(2 cavity) 4.0L(1 cavity)

Blowing pressure

           ≤3.5Mpa

              ≤3.5Mpa

Motion Pressure

           ≤1.0Mpa

              ≤1.0Mpa

Max*diameter*height

       Ø 140XH340mm

          Ø 140XH340mm

Mould thickness

         120~220mm

             120~220mm

Weight

               850kg

                1500kg

Main blowing Machine

      1400*600*1600mm

         1400*600*1600mm*2

Heater

      1750*600*1450mm

         2000*600*1450mm
1、 Adopt new type double bend arm and four pull rod-clamping structure (won the patent).cross direction; middle mould board is move parallel; the distance between two mold boards is adjusted by the chain wheel.Thus, the clamping force is very strong.
2、The machine frame is produced by the whole complete casting bottom, so that the machine are firm and running stable.
3、Adopt straight slide way, reduce the friction and lengthen the life of the machine.
4、 Double start marking button, which is designed for avoiding the injury.
5、 Power saving design that can increase your profits
6、The single direction of pre-form placing and bottle picking, which increase the output.
7、Segregate type air controlling sysem, which is designed for avoiding waste pollution.
8、 The stretching air cylinder is adjusted paralled from front to back, from left to right freely by regulator.
